smacc2::event_generators::EgConditionalGenerator Class Reference

#include <eg_conditional_generator.hpp>

Inheritance diagram for smacc2::event_generators::EgConditionalGenerator:

Collaboration diagram for smacc2::event_generators::EgConditionalGenerator:

Public Member Functions
	EgConditionalGenerator (ConditionalGeneratorMode mode, std::function< bool()> updatePredicate=nullptr)
virtual	~EgConditionalGenerator ()
void	onEntry () override
template<typename TState , typename TSource >
void	onStateAllocation ()
virtual void	update () override
void	setPredicateFunction (std::function< bool()> updatePredicate)
Public Member Functions inherited from smacc2::SmaccEventGenerator
	SmaccEventGenerator ()
virtual	~SmaccEventGenerator ()
template<typename TState , typename TSource >
void	onStateAllocation ()
virtual void	onExit ()
template<typename EventType >
void	postEvent (const EventType &ev)
template<typename EventType >
void	postEvent ()
void	initialize (ISmaccState *ownerState)
virtual void	onInitialized ()
Public Member Functions inherited from smacc2::ISmaccUpdatable
	ISmaccUpdatable ()
	ISmaccUpdatable (rclcpp::Duration duration)
void	executeUpdate (rclcpp::Node::SharedPtr node)
void	setUpdatePeriod (rclcpp::Duration duration)

Public Attributes
ConditionalGeneratorMode	mode_

Private Member Functions
void	checkPredicateAndPost ()

Private Attributes
std::function< void()>	postEventTrue
std::function< void()>	postEventFalse
std::function< bool()>	updatePredicate_

Additional Inherited Members

Detailed Description

Definition at line 44 of file eg_conditional_generator.hpp.

Constructor & Destructor Documentation

EgConditionalGenerator()

smacc2::event_generators::EgConditionalGenerator::EgConditionalGenerator	(	ConditionalGeneratorMode	mode,
		std::function< bool()>	updatePredicate = nullptr
	)

Definition at line 21 of file eg_conditional_generator.cpp.

: mode_(mode), updatePredicate_(updatePredicate)
{
}

~EgConditionalGenerator()

smacc2::event_generators::EgConditionalGenerator::~EgConditionalGenerator ( )

virtual

Definition at line 27 of file eg_conditional_generator.cpp.

{}

Member Function Documentation

checkPredicateAndPost()

void smacc2::event_generators::EgConditionalGenerator::checkPredicateAndPost ( )

private

Definition at line 29 of file eg_conditional_generator.cpp.

{
  if (this->updatePredicate_())
  {
    this->postEventTrue();
  }
  else
  {
    this->postEventFalse();
  }
}

References postEventFalse, postEventTrue, and updatePredicate_.

Referenced by onEntry(), and update().

Here is the caller graph for this function:

onEntry()

void smacc2::event_generators::EgConditionalGenerator::onEntry ( )

overridevirtual

Reimplemented from smacc2::SmaccEventGenerator.

Definition at line 41 of file eg_conditional_generator.cpp.

{
  if (mode_ == ConditionalGeneratorMode::ONE_SHOT)
  {
    this->checkPredicateAndPost();
  }
}

References checkPredicateAndPost(), mode_, and smacc2::event_generators::ONE_SHOT.

Here is the call graph for this function:

onStateAllocation()

template<typename TState , typename TSource >

void smacc2::event_generators::EgConditionalGenerator::onStateAllocation ( )

inline

Definition at line 54 of file eg_conditional_generator.hpp.

  {
    this->postEventTrue = [this]() { this->postEvent<EvTrue<TSource, TState>>(); };
    this->postEventFalse = [this]() { this->postEvent<EvFalse<TSource, TState>>(); };
  }

References postEventFalse, and postEventTrue.

setPredicateFunction()

void smacc2::event_generators::EgConditionalGenerator::setPredicateFunction

(

std::function< bool()>

updatePredicate

)

Definition at line 57 of file eg_conditional_generator.cpp.

{
  updatePredicate_ = updatePredicate;
}

References updatePredicate_.

update()

void smacc2::event_generators::EgConditionalGenerator::update ( )

overridevirtual

Implements smacc2::ISmaccUpdatable.

Definition at line 49 of file eg_conditional_generator.cpp.

{
  if (mode_ == ConditionalGeneratorMode::ON_UPDATE)
  {
    this->checkPredicateAndPost();
  }
}

References checkPredicateAndPost(), mode_, and smacc2::event_generators::ON_UPDATE.

Here is the call graph for this function:

Member Data Documentation

mode_

ConditionalGeneratorMode smacc2::event_generators::EgConditionalGenerator::mode_

Definition at line 61 of file eg_conditional_generator.hpp.

Referenced by onEntry(), and update().

postEventFalse

std::function<void()> smacc2::event_generators::EgConditionalGenerator::postEventFalse

private

Definition at line 68 of file eg_conditional_generator.hpp.

Referenced by checkPredicateAndPost(), and onStateAllocation().

postEventTrue

std::function<void()> smacc2::event_generators::EgConditionalGenerator::postEventTrue

private

Definition at line 67 of file eg_conditional_generator.hpp.

Referenced by checkPredicateAndPost(), and onStateAllocation().

updatePredicate_

std::function<bool()> smacc2::event_generators::EgConditionalGenerator::updatePredicate_

private

Definition at line 69 of file eg_conditional_generator.hpp.

Referenced by checkPredicateAndPost(), and setPredicateFunction().

---

The documentation for this class was generated from the following files:

• smacc2_event_generator_library/eg_conditional_generator/include/eg_conditional_generator/eg_conditional_generator.hpp
• smacc2_event_generator_library/eg_conditional_generator/src/eg_conditional_generator/eg_conditional_generator.cpp
